    GROW R304A DC4.2-6V 208*288 Pixel Fingerprint Module Scanner Reader Free SDK With 1500 Capacity For Arduino Windows Android


    R304s 208*288 Pixel Capacitive Fingerprint Module Scanner

    Description

    ·Communication interface : USB and UART
    ·1:N Identification (One-to-Many)
    ·1:1 Verification (One-to-One)
    ·High speed fingerprint identification algorithm engine
    ·Self study function
    ·Fingerprint feature data read/write functions
    ·Get Feature Data of Captured fingerprint and Verify/Identify Downloaded Feature with Captured
    ·Fingerprint Identify Downloaded Feature with Captured fingerprint
    ·Security Level setting
    ·Able to set BaudRate/ Device ID/Device Password
    ·Operating system:Windows 98, Me, NT4.0, 2000, XP,WIN 7 or Android


    Specifications

    ·Interface:USB 2.0 and UART(3.3V-TTL logic)
    ·Resolution:508 DPI
    ·Work Current: <55mA
    ·Voltage: DC 4.2-6.0V
    ·Fingerprint capacity:1500
    ·Security Level: 1-5, default is 3
    ·Sensor Array: 208*288 pixel
    ·Template Size: 512 bytes
    ·Fingerprint reader module size: 20.4 * 33.4 (mm)
    ·Effective collection area: 12*17.5 (mm)
    ·ScanningSpeed: < 0.2 second
    ·Verification Speed: < 0.3 second
    ·Matching Method: 1:1; 1:N
    ·FRR (False Rejection Ratio): ≤0.01%
    ·FAR (False Acceptance Ratio): ≤0.00001%
    ·Work environment: -20°C ---55°C
    ·Work Humidity: 20-80%
    ·Communications baud rate (UART): (9600 × N) bps where N = 1 ~ 12(default N = 6, ie 57600bps)


    Files

    ·All fingerprint module support with Arduino, Android, Windows, Linux, .Net and so on.
    ·Provide Free SDK Files
    ·Provide User Manual
